ALL TERRAIN DUMPER

FOB Reference Price:Get Latest Price
US $11,000-14,650 / Unit | 1 Unit/Units (Min. Order)
Supply Ability:
700 Unit/Units per Week
Port:
qingdao
Report Suspicious Activity
Overview
Quick Details
Drive Wheel:
4x4
Capacity (Load):
1 - 10t
Horsepower:
28kw
Condition:
New
Transmission Type:
Automatic
Emission Standard:
Euro 3
Fuel Type:
Diesel
Engine Capacity:
< 4L
Gross Vehicle Weight:
3000
Place of Origin:
Shandong, China (Mainland)
Brand Name:
honorsun
Model Number:
FCD30
Dimensions (L x W x H) (mm):
4M*2M*2M
WARRANTY:
12 MONTH
Packaging & Delivery
Packaging Details
2 set in 20GP or 4 sets in 40ft
Delivery Time
within 20 days after the copy of down payment

Specifications

for wet land everglade
suitable for oil plam transport
hydraulic torque convertor with CVT shift

Engine Output: 49.6hp (36.4kw)
Max. Traveling Speed: 7mph (11km/h)
Max. Payload: 6600lbs (3000kg)

EPA Engine; Full Hydrostatic Trans; Rubber Tracks; CE proved
Sauer Danfoss Daikin Hydraulic pumps & motor-gears
Customized to install working units.
Full Warranty Package.
Cheap Parts.


Specifications of  FC30

Operating Weight

Net, unloaded

2500 kg (5000 lb.)



Max. payload

3000 kg (6600 lbs)

Engine

Type

Water-cooled, 4 cyl. Diesel

Model

Changchai 4L50B

Rated output

49.6 hp. (36.4 kw)/2400rpm

Displacement

2834cc

Transmission

Two Speed Full Hydrostatic Transmission  H.S.T 2-pump & 2--motor

Under Carriage

Track Type

Steel-reinforced rubber track

Track width

320mm (12.6 in)

Min. ground clearance

298mm (11 3/4 in)

Ground contact pressure

Unloaded

20.5 kpa (2.97 psi)

loaded

45.3 kpa (6.56 psi)

Performance

Box inner size

1686 x 1530 x 370mm (5ft3/8in x 5ft x 1ft2 1/2in)

Max. dumping angle

59 degree

Dumping height

512mm (20.1 in)

Dump body capacity

Struck

0.9 cu. m (1.18 cu. Yd.)

Heaped

1.27 cu. m (1.66 cu. Yd.)

Travel speed

Stage I

Forward & Backward, 0 ~ 6.3km/h (4 mph)

Stage II

Forward & Backward, 0 ~ 11.3km/h (7 mph)

Slop climbing unloaded

57 degree

Fuel tank capacity



50 L (13.3 gal.)
